Marine Exhaust Hose USCG/SAE J1527 B2|Chemical Delivery Hose

Marine Exhaust Hose USCG/SAE J1527 B2

LT1203

Product Introduction

Applications：Fuel, oil and hydraulic fluids suction and discharge. Suitable for exhaust gas from water cooled stationary or marine diesel engines,Offers maximum flexibility

Product Introduction
Product Parameters

Reinforcement：High tensile textile cords and 4 highly flexible steel helix wires

Cover：Black NBR/PVC blend-abrasion, ozone,hydrocarbon and fire resistant

Working pressure：Constant Pressure-5 Bar(75 PSI)

Temperature Range：--20℃(-40°F)to +100℃(+212°F)

Specifications
Series	I.D. (in.)	I.D. （mm）	O.D. （in.）	O.D. （mm）	Max.W.P. （psi）	W. （kg/m）
LT1204-100	1	25	1.38	35	75	0.64
LT1204-112	11/8	28	1.50	38	75	0.70
LT1204-125	11/4	32	1.65	42	75	0.77
LT1204-137	13/8	35	1.77	45	75	0.83
LT1204-150	11/2	38	1.89	48	75	0.91
LT1204-162	15/8	42	2.05	52	75	0.98
LT1204-175	13/4	45	2.17	55	75	1.04
LT1204-189	17/8	48	2.28	58	75	1.12
LT1204-200	2	51	2.48	63	75	1.44
LT1204-225	21/4	57	2.72	69	75	1.59
LT1204-238	23/8	60	2.91	74	75	1.95
LT1204-250	21/2	63	3.03	77	75	2.04
LT1204-300	3	76	3.54	90	75	2.44
LT1204-350	31/2	90	4.09	104	75	2.90
LT1204-400	4	102	4.57	116	75	3.24
LT1204-450	41/2	115	5.08	129	75	3.62
LT1204-500	5	127	5.55	141	75	3.99
LT1204-600	6	152	6.61	168	75	4.85
LT1204-662	65/8	168	7.24	184	75	5.31
LT1204-800	8	203	8.70	221	75	7.38
